High quality 8kw-1000kw biogas generator

FOB Reference Price:Get Latest Price
US $4,800-380,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
HIGH TECH
Model Number:
HT8GF-HT1000GF
Output Type:
AC Three Phase
Speed:
1500/1200rpm
Frequency:
50/60Hz
Rated Power:
8kw-1000kw
Rated Voltage:
400/230V
Rated Current:
14.4-1800A
control panel:
LCD panel
start method:
electric start
cooling method:
water cooled
function:
ATS AMF
module:
GU304A
regulator:
AVR
noise level:
66dBA
Protechtion class:
IP23
Warranty:
12 months
Certificate:
ISO,CE
Supply Ability
Supply Ability:
400 Set/Sets per Month
Packaging & Delivery
Packaging Details
Export standard package (Plywood package)
Lead Time :
20 days after the deposit

High quality 8kw-1000kw biogas generator



 Advantage of our Biogas engine design



A. Lean burn technical



Lean burn mixture combustion of gas engine is an effective approach for reducing emissions and gas consumption. Due to the difficulty in organize the gas flow in cylinder and the expected air/gas distribution, thus, the successive lean burn engines were concentrated on the 4-Valve engines. In order to intensify the intake swirl and tumbling motions, the intake system of a 2-Valve TJ376QE gas engine was modified. The resulted strong air motions are proved to be beneficial to the air/fuel distribution. All the models of our gas engines adopt such technical improving Gas burn completely, reducing temperature of steam through exhaust. Meanwhile the economic & performance of gas engine high developed.



B. Advantage burning room, Intake & exhaust system



After the company born development and research of Big Bus Single Fuel CNG Electric injection project and in Five National Science and Technical project, it also born development and research of low Emission CNG Bus and en nine Project, then born development of big commercial EURO IV Natural Generator 63 National project.



The engine factory based on WEICHAI strong technology and production ability, cooperated with international famous producer, such as America Woodward, WITCO, Australia AEC companies, developed and produced 4100, 4105, 6105, 6135, D226B, 6160,6170, WT615, WT618, CW200 series gas generator. A new technology called ATR system on Intake & exhaust has been developed based on GT-POWER software.



A research on the engine performance at full load, firing pressure in cylinder, pressure fluctuation in intake and exhaust system, pressure of muffler outlet was made using this model.



For the new technology of compound intake and exhaust system, the preparation process of homogeneous mixture for gas engine was numerically simulated.



In project machinery, the difference of axle journal gyro radius increase because of the diesel engine bent axle grinding cause the difference compression ratio of each cylinder. WEICHAI factory designed suitable burning room & Crankshaft for balance compression ratio of each cylinder. And the petal-type chamber has been changed to squish chamber for improving engine efficiency.



Above technical highly improved the reliability & low gas consumption.



C. Piston with lubricant cooling system



To counter the problem that the injection system sustained a heavy loss in energy and had influence on the service life of oil pump, an improvement on this system together with the piston seal was made, so that good results were achieved.



The pistons in using injection oil cooling system for reducing heat loading to insure reliability of engine.



D. Electrical Speed Governor



An outside-mounted electronic governor is added to a traditional mechanical speed-regulator, which is steady and possible to upgrade a mechanical speed system. All machines choose YSD model governor which import the technical from US GAC Company. The Steady Speed Droop <1% adjusted leading the frequency of generator power steady on 50HZ or 60HZ.



E. HALL ignition system



Under the analyses of the development state for the debris on-line monitor in gearbox, the paper presents a kind of debris on-line monitor, in which the Electromagnet is used to cluster the debris, and HALL Components are used to measure the changes of the concentration for the debris in oil.



The lean combustion and rapid combustion spark-ignition system was put forward and studied with the theory of spark energy conversion and the principle of energy superposition on the base of spark-ignition with capacitance storage.



All machines choose the HALL ignition sensors & high energy firing order 1-3-4-2 for 4 cylinders engine, 1-5-3-6-2-4 for 6 cylinders gas engine.



The engines are easy start even in cold winter. Easily wear parts like Spark plugs extend longer life more then 2000 hours.



F. Special Grade of gas mixing device, pressure regulator.



Choose Special Grade of gas mixing device & pressure regulator application of most gas pipeline & Gas storage tank.



G. Protection system & monitor



HARSON GU641 24 hours generator monitor insure the safety & reliability performance.



Main function:



1. 24 hours monitor on the status of engine, alternator, battery, loading.



2. Emergency stop protection for high temperature and overloaded



3. When the speed become over 110% engine must stop by solenoid valve and also will be stop in case of the following :



   a. Cooling temperature high,

   b. Oil pressure become low,

   c. Over Speed

   d. Water level become low,

   e. Oil level become low ,

   f. Oil temperature become high,

   g. Oil pressure become high,

   h. start failure,

   i. stop failure,

   j. sensor short/plough, It also has light - sound alarm for the same reasons above



4. Show the exactly speed /water temperature/fuel pressure as dig splay.



5. Show the mode like ready, start, pre-heat, cranking, delay, run, stop, etc. as Real-time.



6. Hour counter



7. ATS after connect the switch



8. Paralleling the electric to Main city power if required.



Technical requirement:  (suggested on excellent machine working)



1) Operating condition:    Ambient temperature: <45°C     Sea level: <1000m    Humidity ratio:  <60%

2) Lubricating Oil   15W/40L-ECD suggested

3) Gas intake Pressure <0.45MPa

4) Impurity particle size <5μm

5) content of sulfur ≤250mg/Nm³

6) Methane content (CH4) >50% (>5500kcal)

Why choose us

Why Choose Us.jpg

Main Partners

Main Cooperative Partne.jpg

Company Information

Company Information.jpg

Our Services



Competitive service:



1) More than 15 years advanced production experience.


2) As OEM factory, we have obvious competitive in price and leading times.


3) Widely power range from 8KW to 1200KW.


4) Provide debugging and maintenance service to you.



5) Professional 8 Hours testing for Generator before shipment.


6) 1500 hours warranty on the spare parts free provide & technical support in machine life.

 Our Services.jpg

Packaging & Shipping



1) Shipment:  Shipment  by FCL or LCL

2) Delivery time: 7-15 working days after the deposit.
3) Package:  Outside package: Plywood case on export standard.
                         Inner package: Shrinking film with foam.

Packaging & Shipping.jpg
